Engineering the Foundation of Intelligent Systems
At EmbedTekDesign, we transform complex concepts into high-performance hardware architectures. Our approach to hardware engineering combines meticulous schematic design with advanced power and signal management, ensuring your product is reliable, scalable, and production-ready.
Embedded Hardware
Key Highlights
Why Choose This Service
System Architecture & Design Strategy
- Platform Selection: Expert mapping of ARM Cortex, RISC-V, FPGA, or SoC platforms to your specific use case.
- High-Speed Interface Design: Seamless integration of DDR4/5, PCIe, USB 3.0, and Gigabit Ethernet.
- Low-Power Optimization: Specialized circuitry for battery-operated and energy-harvesting IoT devices.
Core Capability: Schematic Development
- Component Engineering: Rigorous selection of AEC-Q (Automotive) or Industrial-grade components to prevent supply chain bottlenecks.
- Signal Integrity Analysis: Pre-layout simulation to mitigate EMI/EMC issues and ensure clean data transmission across high-speed buses.
- Mixed-Signal Expertise: Precise isolation of sensitive analog sensors from high-frequency digital noise.
The EmbedTekDesign Advantage
- DFM-Centric Design: Every schematic is developed with Design for Manufacturing (DFM) in mind, ensuring a smooth transition from prototype to mass production.
- Compliance-First Approach: We integrate protection and filtering at the schematic level to meet global CE, FCC, and RoHS certification requirements on the first pass.
- Full Lifecycle Support: From initial component selection to End-of-Life (EOL) management, we ensure your hardware remains viable for years.
Specifications
Technical Specifications
| Category | Supported Capabilities |
|---|---|
| Processor Support | STM32, ESP32, nRF52/53, i.MX Series, NVIDIA Jetson, Xilinx FPGA |
| Communication | CAN-FD, RS485, Industrial Ethernet, I2C, SPI, UART |
| Wireless Protocols | Wi-Fi 6E, Bluetooth 5.4 (BLE), LoRaWAN, Zigbee, NB-IoT |
| Sensor Fusion | High-precision MEMS, IMUs, LiDAR, and CMOS Image Sensors |
Ready to Get Started?
Contact us today for service information, technical details, or to request a quote.
